Description

Predictive iDash till now had used a Wifi link to transfer Race-Keeper HE/SE data to your mobile device running the Predictive iDash app to allow it to display your lap timing information.

Now you can connect your iOS or Android device to the Race-Keeper HE with a specially developed adaptor cable.
If you were having trouble connecting over WiFi then this is the answer.

This cable kit plugs into the USB socket on your existing iDash Race-Keeper cable. The other end of the adapter cable connects to your new Android device with a USB C connector.

Once the ethernet adapter is connected to power from the Race-Keeper HE and to the Android device, “Ethernet” will appear in the Connections, More Connections page in the Settings menu.

Select “Ethernet” in order to access the ethernet configuration details. The Ethernet connection can be configured to use either DHCP or a static IP address. The default is DHCP, change this to Static.
Configure the Ethernet connection settings as follows:
IP Address (Select Static)
192.168.0.55

Netmask
255.255.255.0

DNS
192.168.0.1

Default Gateway
192.168.0.1

For help configuring the Ethernet connection on your device, send us an email to info@race-keeper.com

Additional information

Weight 0.3 lbs
Dimensions 10 × 6 × 6 in

We know that your time on track is limited, but so is the time available between sessions, during which you have to review your video/data, along with a whole host of other things. That is why we have made our video data analysis software so simple to use.

Although we believe Comparo HD is the simplest video data logging software on the market, to some we appreciate it may appear daunting at first glance, due to all the text, graphs and buttons. That is why we actively encourage you to download a copy of Comparo HD for free, along with some sample video/data and have a go at comparing laps and analysing data for yourself.

Comparo HD is Race-Keepers video data analysis software which plays synchronized video alongside course map and data traces, including speed, lap number, lap time, G forces, as well as any other data streams available via OBD-II, ECU/CAN or from Analog/Digital sensors.

It presents all of this information in a single, combined view so that you can instantly start analyzing your ontrack performance straight away. Data and video is automatically syncronized so there is no unnecessary setup or configuring that is required before you can playback your outing.
